Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Mounting methodWall surface mounted
Power supply systemPeripheral (individual battery)
Width184mm
Connection typePlug-in connection
Suitable for labelling typeOther
Colour housingGrey
Voltage typeAC
Number of poles6
Lamp typeLED not exchangeable
Protection classI
Conductor cross section2.5mm²
Type of control gearLED operating device current-controlled
Height/depth160mm
Lamp holderNone
Number of lighting heads1
Length303mm
Material housingAluminium
With remote switch connectionYes
Battery qualityLithium-ions
Luminaire with limited surface temperature, sign "D“Yes
Monitoring equipmentSafety module for monitoring (central feeded system)
Impact strengthIK10
With light sourceYes
Degree of protection (IP)IP65
Material coverPlastic, transparent
Nominal voltage220 - 240V
Max. system power7W
Type of wiringSuitable for through wiring
Colour temperature6500 - 6500K
Rated life time L70/B50 at 25 °C50000h
Rated luminous flux according to IEC 62722-2-1250lm
Light distributorFocal lens
Power factor0.91
Rated ambient temperature according to IEC62722-2-15 - 35°C
Nominal operation time1 - 8h
With pictogramNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
40071354874 | Wall 1-8h D CGLine+, IP65, asimetrična optika
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Luminaires
- Emergency luminaire
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Mounting method
Wall surface mounted
Power supply system
Peripheral (individual battery)
Width
184mm
Connection type
Plug-in connection
Suitable for labelling type
Other
Colour housing
Grey
Voltage type
AC
Number of poles
6
Lamp type
LED not exchangeable
Protection class
I
Conductor cross section
2.5mm²
Type of control gear
LED operating device current-controlled
Height/depth
160mm
Lamp holder
None
Number of lighting heads
1
Length
303mm
Material housing
Aluminium
With remote switch connection
Battery quality
Lithium-ions
Luminaire with limited surface temperature, sign "D“
Monitoring equipment
Safety module for monitoring (central feeded system)
Impact strength
IK10
With light source
Degree of protection (IP)
IP65
Material cover
Plastic, transparent
Nominal voltage
220 .. 240V
Max. system power
7W
Type of wiring
Suitable for through wiring
Colour temperature
6500 .. 6500K
Rated life time L70/B50 at 25 °C
50000h
Rated luminous flux according to IEC 62722-2-1
250lm
Light distributor
Focal lens
Power factor
0.91
Rated ambient temperature according to IEC62722-2-1
5 .. 35°C
Nominal operation time
1 .. 8h
With pictogram
