Details
- •Sensors
- •End switch
- •1 KOM
- •ABB
Technical specifications
Rated operation current Ie at AC-15, 230 V3.1A
Rated operation current Ie at DC-13, 230 V0.4A
Material housingMetal
Suitable for safety functionsNo
Coating housingPowder coating
Switching functionQuick-break switch
Type of interface for safety communicationNone
Type of electric connectionCable entry metrical
Forced openingNo
Number of safety auxiliary contacts0
Type of interfaceNone
Degree of protection (IP)IP66
Width sensor50mm
Height of sensor130mm
Output electronicNo
Explosion safety category for gasNone
Rated operation current Ie at AC-15, 24 V10A
Diameter sensor0mm
Switching function latchingNo
Rated operation current Ie at AC-15, 125 V5.5A
Length of sensor52mm
With status indicationNo
Rated operation current Ie at DC-13, 125 V0.6A
Type of control elementPlunger
Explosion safety category for dustNone
Rated operation current Ie at DC-13, 24 V6A
Construction type housingCuboid
Number of contacts as change-over contact0
Number of contacts as normally closed contact1
Number of contacts as normally open contact1
Ambient temperature during operating-25 - 70°C
Alignment of the control elementOther
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SBV011952R1211 | LS32M52B11
