Details
- •Sensors
- •End switch
- •1 KOM
- •ABB
Technical specifications
Type of electric connectionWith cable preassembled
Rated operation current Ie at AC-15, 230 V3A
Explosion safety category for gasNone
Material housingMetal
With status indicationNo
Suitable for safety functionsNo
Switching functionQuick-break switch
Coating housingPowder coating
Type of interface for safety communicationNone
Rated operation current Ie at DC-13, 230 V0.27A
Construction type housingCuboid
Output electronicNo
Explosion safety category for dustNone
Ambient temperature during operating-25 - 70°C
Degree of protection (NEMA)6
Alignment of the control elementOther
Rated operation current Ie at AC-15, 125 V5.5A
Number of contacts as normally open contact1
Diameter sensor0mm
Rated operation current Ie at DC-13, 125 V0.55A
Type of interfaceNone
Rated operation current Ie at AC-15, 24 V10A
Number of safety auxiliary contacts0
Type of control elementPlunger
Switching function latchingNo
Number of contacts as normally closed contact1
Number of contacts as change-over contact0
Rated operation current Ie at DC-13, 24 V2.8A
Forced openingNo
Length of sensor16mm
Degree of protection (IP)IP67
Width sensor30mm
Height of sensor60mm
