Details
- •Sensors
- •End switch
- •1 KOM
- •ABB
Technical specifications
Switching functionQuick-break switch
Rated operation current Ie at DC-13, 230 V0.27A
Suitable for safety functionsNo
Material housingPlastic
Rated operation current Ie at AC-15, 230 V3A
Construction type housingCuboid
Explosion safety category for gasNone
Coating housingOther
Number of safety auxiliary contacts0
Rated operation current Ie at AC-15, 24 V10A
Type of interfaceNone
Type of electric connectionWith cable preassembled
With status indicationNo
Output electronicNo
Type of control elementPlunger
Rated operation current Ie at AC-15, 125 V5.5A
Type of interface for safety communicationNone
Rated operation current Ie at DC-13, 24 V2.8A
Rated operation current Ie at DC-13, 125 V0.55A
Explosion safety category for dustNone
Forced openingNo
Number of contacts as normally open contact1
Number of contacts as normally closed contact1
Length of sensor16mm
Switching function latchingNo
Ambient temperature during operating-25 - 70°C
Diameter sensor0mm
Alignment of the control elementOther
Degree of protection (NEMA)6
Number of contacts as change-over contact0
Degree of protection (IP)IP67
Width sensor30mm
Height of sensor70mm
