1SCA123767R1001 | OTDC200U11
Code: 2001269
ManufacturerABB
Catalog number1SCA123767R1001
TypeSwitch disconnector (low voltage)
CategorySwitch disconnector
EAN code6417019545295
Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Width115.5mm
Number of auxiliary contacts as normally open contact0
Height176mm
Depth83.5mm
Rated operation power at AC-3, 400 V-kW
Width in number of modular spacings-
Degree of protection (IP), front sideIP20
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq-kA
Type of electrical connection of main circuitBolt connection
Number of switches1
Version as main switchYes
Version as safety switchNo
Rated operating voltage1000 - 1000V
Number of auxiliary contacts as change-over contact0
InterlockableNo
Motor drive integratedNo
Version as emergency stop installationNo
Type of control elementOther
Suitable for floor mountingNo
Rated short-time withstand current lcw-kA
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V-kW
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Voltage release optionalNo
Suitable for front mounting centreNo
Rated permanent current at AC-23, 400 V-A
Suitable for front mounting 4-holeYes
Version as reversing switchNo
Switching power at 400 V-kW
Rated permanent current at AC-21, 400 V-A
Degree of protection (NEMA)1
Motor drive optionalNo
With pre-assembled cablingNo
Device constructionBuilt-in device fixed built-in technique
Rated permanent current Iu250A
Number of poles2
Max. rated operation voltage Ue AC-V
