Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Height262mm
Width185.4mm
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu100A
Rated operation power at AC-3, 400 V-kW
Depth90.5mm
Rated operating voltage1000 - 1000V
Number of poles4
Width in number of modular spacings-
Conditioned rated short-circuit current Iq-kA
Degree of protection (IP), front sideIP20
Version as emergency stop installationNo
Number of auxiliary contacts as change-over contact0
InterlockableNo
Version as safety switchNo
Motor drive integratedNo
Number of switches1
Type of electrical connection of main circuitBolt connection
Version as main switchYes
Rated operation power at AC-23, 400 V-kW
Rated short-time withstand current lcw-kA
Suitable for distribution board installationYes
Version as maintenance-/service switchYes
Suitable for floor mountingNo
Suitable for front mounting centreNo
Suitable for front mounting 4-holeYes
Type of control elementOther
Rated permanent current at AC-21, 400 V-A
Suitable for intermediate mountingNo
Switching power at 400 V-kW
Version as reversing switchNo
Device constructionBuilt-in device fixed built-in technique
Motor drive optionalNo
Max. rated operation voltage Ue AC-V
Voltage release optionalNo
With pre-assembled cablingNo
Rated permanent current at AC-23, 400 V-A
Degree of protection (NEMA)1
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA125824R1001 | OTDC100E22
