Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Number of poles3
Rated operation power at AC-3, 400 V-kW
Conditioned rated short-circuit current Iq6.5kA
Rated operating voltage750 - 750V
Number of auxiliary contacts as change-over contact0
Number of switches1
Degree of protection (IP), front sideIP65
Number of auxiliary contacts as normally open contact2
Motor drive integratedNo
InterlockableNo
Rated permanent current Iu32A
Number of auxiliary contacts as normally closed contact2
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-23, 400 V9kW
Rated permanent current at AC-23, 400 V20A
Device constructionComplete device in housing
Suitable for distribution board installationNo
Type of control elementTurn button
Suitable for front mounting centreNo
Rated permanent current at AC-21, 400 V25A
Version as emergency stop installationNo
Version as maintenance-/service switchYes
Suitable for front mounting 4-holeYes
Suitable for intermediate mountingNo
Voltage release optionalNo
Colour control elementBlack
Motor drive optionalNo
Version as reversing switchNo
Version as main switchYes
Degree of protection (NEMA)Other
Switching power at 400 V9kW
Rated short-time withstand current lcw-kA
Max. rated operation voltage Ue AC750V
Version as safety switchYes
Suitable for floor mountingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA152722R1001 | OTA25S3BX-ATEX ENCLOSED SAFETY SWITCH
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of poles
3
Rated operation power at AC-3, 400 V
-kW
Conditioned rated short-circuit current Iq
6.5kA
Rated operating voltage
750 .. 750V
Number of auxiliary contacts as change-over contact
0
Number of switches
1
Degree of protection (IP), front side
IP65
Number of auxiliary contacts as normally open contact
2
Motor drive integrated
Interlockable
Rated permanent current Iu
32A
Number of auxiliary contacts as normally closed contact
2
Type of electrical connection of main circuit
Screw connection
Rated operation power at AC-23, 400 V
9kW
Rated permanent current at AC-23, 400 V
20A
Device construction
Complete device in housing
Suitable for distribution board installation
Type of control element
Turn button
Suitable for front mounting centre
Rated permanent current at AC-21, 400 V
25A
Version as emergency stop installation
Version as maintenance-/service switch
Suitable for front mounting 4-hole
Suitable for intermediate mounting
Voltage release optional
Colour control element
Black
Motor drive optional
Version as reversing switch
Version as main switch
Degree of protection (NEMA)
Other
Switching power at 400 V
9kW
Rated short-time withstand current lcw
-kA
Max. rated operation voltage Ue AC
750V
Version as safety switch
Suitable for floor mounting
