Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Overload release current setting- - -A
Adjustment range short-term delayed short-circuit release- - -A
Adjustment range undelayed short-circuit release- - -A
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Number of poles3
With switched-off indicatorNo
Rated permanent current Iu600A
Complete device with protection unitNo
With integrated under voltage releaseNo
Rated voltage240 - 600V
Motor drive integratedNo
Device constructionBuilt-in device fixed built-in technique
Type of control elementToggle
Type of electrical connection of main circuitBolt connection
Integrated earth fault protectionNo
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz100kA
Motor drive optionalYes
Position of connection for main current circuitFront side
Degree of protection (IP)IP20
DIN rail (top hat rail) mounting optionalYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA102686R1 | XT5L 600 BREAKING PART 3P F F UL/CSA
