Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Built-in depth75mm
Voltage typeOther
Explosion-proofNo
Rated voltage240V
Current limiting class3
Width in number of modular spacings1
Over voltage category3
Degree of protection (IP)IP20
Pollution degree3
Power loss1.3W
Connectable conductor cross section solid-core0.75 - 35mm²
Rated insulation voltage Ui440V
Ambient temperature during operating-25 - 60°C
Release characteristicC
Number of protected poles1
Frequency50 - 60Hz
Connectable conductor cross section multi-wired0.75 - 25mm²
Rated current0.5A
Concurrently switching neutral conductorNo
Number of poles (total)1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V25kA
Flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V25kA
Additional equipment possibleYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Rated impulse withstand voltage Uimp4kV
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CCS571001R0984 | S401M-C0.5
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specificationsRelated products
Technical specifications
Built-in depth
75mm
Voltage type
Other
Explosion-proof
Rated voltage
240V
Current limiting class
3
Width in number of modular spacings
1
Over voltage category
3
Degree of protection (IP)
IP20
Pollution degree
3
Power loss
1.3W
Connectable conductor cross section solid-core
0.75 .. 35mm²
Rated insulation voltage Ui
440V
Ambient temperature during operating
-25 .. 60°C
Release characteristic
C
Number of protected poles
1
Frequency
50 .. 60Hz
Connectable conductor cross section multi-wired
0.75 .. 25mm²
Rated current
0.5A
Concurrently switching neutral conductor
Number of poles (total)
1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
25kA
Flush-mounted installation
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
25kA
Additional equipment possible
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Rated impulse withstand voltage Uimp
4kV
