Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Release characteristicZ
Current limiting class3
Rated current50A
Rated voltage230V
Built-in depth69mm
Voltage typeOther
Frequency50 - 60Hz
Rated insulation voltage Ui440V
Pollution degree3
Ambient temperature during operating-40 - 70°C
Over voltage category3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Explosion-proofNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Number of poles (total)2
Flush-mounted installationNo
Rated impulse withstand voltage Uimp4kV
Connectable conductor cross section solid-core0.75 - 35mm²
Additional equipment possibleYes
Degree of protection (IP)IP20
Connectable conductor cross section multi-wired0.75 - 25mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Number of protected poles1
Power loss10W
Concurrently switching neutral conductorYes
Width in number of modular spacings2.0
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CDS271446R0578 | S201MT-Z50NA
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Release characteristic
Z
Current limiting class
3
Rated current
50A
Rated voltage
230V
Built-in depth
69mm
Voltage type
Other
Frequency
50 .. 60Hz
Rated insulation voltage Ui
440V
Pollution degree
3
Ambient temperature during operating
-40 .. 70°C
Over voltage category
3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Explosion-proof
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
15kA
Number of poles (total)
2
Flush-mounted installation
Rated impulse withstand voltage Uimp
4kV
Connectable conductor cross section solid-core
0.75 .. 35mm²
Additional equipment possible
Degree of protection (IP)
IP20
Connectable conductor cross section multi-wired
0.75 .. 25mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
15kA
Number of protected poles
1
Power loss
10W
Concurrently switching neutral conductor
Width in number of modular spacings
2.0
