Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V-kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V-kA
Number of poles (total)2
Release characteristicZ
Number of protected poles2
Rated voltage440V
Rated current30A
Frequency50 - 60Hz
Voltage typeAC/DC
Concurrently switching neutral conductorNo
Suitable for flush-mounted installationNo
Over voltage category3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V11.2kA
Current limiting class3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Pollution degree3
Width in number of modular spacings2
Additional equipment possibleYes
Degree of protection (IP)IP20
Connectable conductor cross section solid-core0 - 35mm²
Ambient temperature during operating-25 - 55°C
Rated insulation voltage Ui440V
Connectable conductor cross section multi-wired0 - 25mm²
Built-in depth69mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CDS272337R0528 | SU202M-Z30
