Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Built-in depth69mm
Release characteristicK
Number of protected poles4
Rated current0.3A
Rated voltage440V
Rated insulation voltage Ui440V
Number of poles (total)4
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Frequency50 - 60Hz
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V-kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Power loss6.8W
Voltage typeOther
Current limiting class3
Over voltage category3
Additional equipment possibleYes
Flush-mounted installationNo
Width in number of modular spacings4.0
Degree of protection (IP)IP20
Ambient temperature during operating-40 - 70°C
Concurrently switching neutral conductorNo
Pollution degree3
Explosion-proofNo
Connectable conductor cross section solid-core0.75 - 35mm²
Connectable conductor cross section multi-wired0.75 - 25mm²
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CDS274445R0117 | S204MT-K0,3
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Built-in depth
69mm
Release characteristic
K
Number of protected poles
4
Rated current
0.3A
Rated voltage
440V
Rated insulation voltage Ui
440V
Number of poles (total)
4
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Rated impulse withstand voltage Uimp
4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Frequency
50 .. 60Hz
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
-kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
15kA
Power loss
6.8W
Voltage type
Other
Current limiting class
3
Over voltage category
3
Additional equipment possible
Flush-mounted installation
Width in number of modular spacings
4.0
Degree of protection (IP)
IP20
Ambient temperature during operating
-40 .. 70°C
Concurrently switching neutral conductor
Pollution degree
3
Explosion-proof
Connectable conductor cross section solid-core
0.75 .. 35mm²
Connectable conductor cross section multi-wired
0.75 .. 25mm²
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
