Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact0
Type of control elementToggle
Degree of protection (IP)IP20
Overload release current setting100.0 - 250A
Rated permanent current Iu400A
Number of auxiliary contacts as normally open contact0
Number of poles3
Rated voltage240 - 600V
With integrated under voltage releaseNo
Position of connection for main current circuitFront side
Motor drive integratedNo
Type of electrical connection of main circuitBolt connection
DIN rail (top hat rail) mounting optionalYes
Suitable for DIN rail (top hat rail) mountingNo
Device constructionBuilt-in device fixed built-in technique
Adjustment range undelayed short-circuit release1500 - 3250A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz65kA
Motor drive optionalYes
Adjustment range short-term delayed short-circuit release- - -A
Integrated earth fault protectionNo
With switched-off indicatorNo
Complete device with protection unitYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA102541R1 | XT5H 400 EKIPM DIP LIU(MPCB)250 3P FF UL
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as change-over contact
0
Type of control element
Toggle
Degree of protection (IP)
IP20
Overload release current setting
100.0 .. 250A
Rated permanent current Iu
400A
Number of auxiliary contacts as normally open contact
0
Number of poles
3
Rated voltage
240 .. 600V
With integrated under voltage release
Position of connection for main current circuit
Front side
Motor drive integrated
Type of electrical connection of main circuit
Bolt connection
DIN rail (top hat rail) mounting optional
Suitable for DIN rail (top hat rail) mounting
Device construction
Built-in device fixed built-in technique
Adjustment range undelayed short-circuit release
1500 .. 3250A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
65kA
Motor drive optional
Adjustment range short-term delayed short-circuit release
- .. -A
Integrated earth fault protection
With switched-off indicator
Complete device with protection unit
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
