Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Rated current6A
Frequency50 - 60Hz
Rated voltage230V
Built-in depth82mm
Voltage typeOther
Release characteristicC
Rated insulation voltage Ui440V
Over voltage category3
Explosion-proofNo
Current limiting class3
Width in number of modular spacings1
Pollution degree4
Concurrently switching neutral conductorNo
Number of poles (total)1
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V-kA
Flush-mounted installationNo
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V-kA
Rated impulse withstand voltage Uimp4kV
Additional equipment possibleYes
Number of protected poles1
Connectable conductor cross section multi-wired0.75 - 25mm²
Ambient temperature during operating-25 - 60°C
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Connectable conductor cross section solid-core0.75 - 35mm²
Degree of protection (IP)IP20
Power loss1.8W
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CCS551001R0064 | S401E-C6
