Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •LEGRAND
Technical specifications
Rated operation power at AC-23, 400 V-kW
Rated operation power at AC-3, 400 V-kW
Number of switches-
Degree of protection (IP), front sideIP20
Version as main switchYes
Number of auxiliary contacts as normally closed contact0
Version as emergency stop installationYes
Conditioned rated short-circuit current Iq-kA
Rated permanent current Iu63A
Number of poles2
Version as maintenance-/service switchYes
Type of electrical connection of main circuitScrew connection
Rated operating voltage24 - 1000V
Type of control elementToggle
Version as safety switchYes
Number of auxiliary contacts as normally open contact0
Motor drive integratedNo
Number of auxiliary contacts as change-over contact3
InterlockableYes
Suitable for floor mountingYes
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Suitable for front mounting centreNo
Motor drive optionalYes
Rated permanent current at AC-21, 400 V63A
Rated permanent current at AC-23, 400 V-A
Device constructionComplete device in housing
Suitable for front mounting 4-holeYes
Colour control elementRed
Switching power at 400 V-kW
Version as reversing switchNo
Voltage release optionalYes
Rated short-time withstand current lcw1kA
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
414246 | 63A 1000V DC SKL
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector (low voltage)
- 1 KOM
- LEGRAND
DetailsTechnical specifications
Technical specifications
Rated operation power at AC-23, 400 V
-kW
Rated operation power at AC-3, 400 V
-kW
Number of switches
-
Degree of protection (IP), front side
IP20
Version as main switch
Number of auxiliary contacts as normally closed contact
0
Version as emergency stop installation
Conditioned rated short-circuit current Iq
-kA
Rated permanent current Iu
63A
Number of poles
2
Version as maintenance-/service switch
Type of electrical connection of main circuit
Screw connection
Rated operating voltage
24 .. 1000V
Type of control element
Toggle
Version as safety switch
Number of auxiliary contacts as normally open contact
0
Motor drive integrated
Number of auxiliary contacts as change-over contact
3
Interlockable
Suitable for floor mounting
Suitable for distribution board installation
Suitable for intermediate mounting
Suitable for front mounting centre
Motor drive optional
Rated permanent current at AC-21, 400 V
63A
Rated permanent current at AC-23, 400 V
-A
Device construction
Complete device in housing
Suitable for front mounting 4-hole
Colour control element
Red
Switching power at 400 V
-kW
Version as reversing switch
Voltage release optional
Rated short-time withstand current lcw
1kA
Max. rated operation voltage Ue AC
1000V
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
