Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Depth68mm
Height168mm
Width138mm
Number of poles3
Conditioned rated short-circuit current Iq-kA
Rated permanent current Iu40A
Number of auxiliary contacts as normally open contact0
Width in number of modular spacings-
Rated operation power at AC-23, 400 V11kW
Number of auxiliary contacts as change-over contact0
Number of switches1
Rated operating voltage690 - 690V
Motor drive integratedNo
Version as maintenance-/service switchYes
Number of auxiliary contacts as normally closed contact0
Version as safety switchNo
Degree of protection (IP), front sideIP65
Version as emergency stop installationNo
InterlockableYes
Rated operation power at AC-3, 400 V-kW
Version as main switchYes
Type of control elementRocker lever
Colour control elementGrey
Rated short-time withstand current lcw-kA
Suitable for front mounting centreNo
Suitable for floor mountingNo
Suitable for front mounting 4-holeNo
Suitable for distribution board installationYes
Max. rated operation voltage Ue AC690V
Voltage release optionalNo
Suitable for intermediate mountingNo
Rated permanent current at AC-21, 400 V-A
Switching power at 400 V11kW
Motor drive optionalNo
Device constructionComplete device in housing
Version as reversing switchNo
Degree of protection (NEMA)Other
Rated permanent current at AC-23, 400 V25A
With pre-assembled cablingNo
