11BG0910A024
Code: 2025175
ManufacturerLovato
Catalog number11BG0910A024
TypePower contactor, AC switching
Category-
EAN code8013975080023
Details
- •Low-voltage control systems
- •Power contactor, AC switching
- •1 KOM
- •LOVATO
Technical specifications
Modular versionNo
Voltage type for actuatingAC
Type of electrical connection of main circuitScrew connection
Rated control supply voltage Us at AC 60HZ24 - 24V
Rated operation current Ie at AC-4, 400 V4A
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Rated operation current Ie at AC-1, 400 V20A
Rated operation power at AC-3, 400 V4kW
Number of auxiliary contacts as normally open contact1
Number of auxiliary contacts as normally closed contact0
Rated operation current Ie at AC-3, 400 V9A
Rated control supply voltage Us at AC 50HZ24 - 24V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
11BG0910A024
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Power contactor, AC switching
- 1 KOM
- LOVATO
DetailsTechnical specifications
Technical specifications
Modular version
Voltage type for actuating
AC
Type of electrical connection of main circuit
Screw connection
Rated control supply voltage Us at AC 60HZ
24 .. 24V
Rated operation current Ie at AC-4, 400 V
4A
Number of normally closed contacts as main contact
0
Number of normally open contacts as main contact
3
Rated operation current Ie at AC-1, 400 V
20A
Rated operation power at AC-3, 400 V
4kW
Number of auxiliary contacts as normally open contact
1
Number of auxiliary contacts as normally closed contact
0
Rated operation current Ie at AC-3, 400 V
9A
Rated control supply voltage Us at AC 50HZ
24 .. 24V
