Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Version as safety switchNo
Rated permanent current at AC-23, 400 V-A
Rated operation power at AC-23, 400 V-kW
Rated permanent current at AC-21, 400 V-A
Version as main switchYes
Version as reversing switchNo
Number of switches1
Max. rated operation voltage Ue AC480V
Version as emergency stop installationNo
Rated operating voltage- - -V
Switching power at 400 V-kW
Version as maintenance-/service switchYes
Rated permanent current Iu-A
Rated short-time withstand current lcw18kA
Rated operation power at AC-3, 400 V-kW
Conditioned rated short-circuit current Iq-kA
Number of poles3
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Voltage release optionalNo
Motor drive optionalNo
Motor drive integratedYes
Number of auxiliary contacts as change-over contact0
Suitable for floor mountingNo
Suitable for front mounting centreNo
Suitable for intermediate mountingNo
Suitable for front mounting 4-holeYes
Type of control elementLong turning handle
Type of electrical connection of main circuitBolt connection
Device constructionBuilt-in device plug-in technique
Suitable for distribution board installationYes
InterlockableNo
Degree of protection (IP), front sideIP20
Height305mm
Width330mm
With pre-assembled cablingNo
Degree of protection (NEMA)1
Width in number of modular spacings-
Depth183mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA153313R1001 | OXA200U3X3QT
