Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Version as maintenance-/service switchYes
Version as safety switchNo
Version as emergency stop installationNo
Max. rated operation voltage Ue AC480V
Version as main switchYes
Version as reversing switchNo
Number of switches1
Rated permanent current at AC-21, 400 V-A
Rated operation power at AC-3, 400 V-kW
Switching power at 400 V-kW
Rated permanent current Iu-A
Rated operating voltage- - -V
Rated short-time withstand current lcw25kA
Rated permanent current at AC-23, 400 V-A
Conditioned rated short-circuit current Iq-kA
Rated operation power at AC-23, 400 V-kW
Number of poles3
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Motor drive integratedYes
Voltage release optionalNo
Suitable for front mounting centreNo
Suitable for front mounting 4-holeYes
Motor drive optionalNo
Suitable for floor mountingNo
Suitable for distribution board installationYes
Device constructionBuilt-in device plug-in technique
InterlockableNo
Suitable for intermediate mountingNo
With pre-assembled cablingNo
Type of control elementLong turning handle
Degree of protection (IP), front sideIP20
Type of electrical connection of main circuitBolt connection
Width390mm
Height305mm
Degree of protection (NEMA)1
Depth183mm
Width in number of modular spacings-
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA153479R1001 | OXB260U3X4QB
