DILM7-01(60VDC)-PI | Contactor 7A/3kW AC-3, 22A AC-1, 3pole+1NC, Push-In terminals, Uc=60V DC
Code: 2034693
ManufacturerEaton
Catalog numberEP-401305
TypePower contactor, AC switching
CategoryPower contactor, AC switching
EAN code4015082967703
Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at DC60 - 60V
Voltage type for actuatingDC
Number of normally closed contacts as main contact0
Rated operation power at AC-4, 400 V2.2kW
Operating voltage at AC 60 Hz24 - 690V
Number of normally open contacts as main contact3
Type of electrical connection of main circuitSpring clamp connection
Rated operation current Ie at AC-1, 400 V22A
Rated operation current Ie at AC-4, 400 V5A
Operating voltage at AC 50 Hz24 - 690V
Rated operation power NEMA2.2kW
Modular versionNo
Width45mm
Depth75mm
Height68mm
Rated operation power at AC-3, 400 V3kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact1
Rated operation current Ie at AC-3, 400 V7A
Rated control supply voltage Us at AC 50HZ0 - 0V
