Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
Adjustment range undelayed short-circuit release400 - 3000A
With thermal protectionYes
Phase failure sensitiveYes
Switch off techniqueElectronic
Rated operating voltage690 - 690V
Rated operation power at AC-3, 230 V55kW
Power loss33W
Device constructionBuilt-in device fixed built-in technique
Type of electrical connection of main circuitOther
With integrated under voltage releaseNo
Type of control elementRocker lever
With integrated auxiliary switchNo
Height195mm
Width105mm
Degree of protection (IP)IP20
Depth149mm
Rated operation power at AC-3, 400 V110kW
Rated permanent current Iu200A
Number of poles3
Overload release current setting80 - 200A
Rated short-circuit breaking capacity lcu at 400 V, AC150kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMH2-MX200-BT-NA | Circuit-breaker, 3p, Ic=100kA(480V), In=200A, motor.prot, PXR20(LSI), fixed,
