Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
Overload release current setting36 - 90A
Adjustment range undelayed short-circuit release180 - 1260A
With thermal protectionYes
Phase failure sensitiveYes
Rated permanent current Iu90A
Switch off techniqueElectronic
Rated operating voltage690 - 690V
Rated operation power at AC-3, 230 V22kW
Rated operation power at AC-3, 400 V45kW
Device constructionBuilt-in device fixed built-in technique
Type of electrical connection of main circuitOther
With integrated under voltage releaseNo
Type of control elementRocker lever
With integrated auxiliary switchNo
Rated short-circuit breaking capacity lcu at 400 V, AC150kA
Number of poles3
Degree of protection (IP)IP20
Width105mm
Height195mm
Depth149mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMH2-MX90-BT-NA | Circuit-breaker, 3p, Ic=100kA(480V), In=90A, motor.prot, PXR20(LSI), fixed,
