Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
Overload release current setting36 - 90A
With thermal protectionYes
Adjustment range undelayed short-circuit release180 - 1260A
Phase failure sensitiveYes
Rated permanent current Iu90A
Switch off techniqueElectronic
Rated operating voltage690 - 690V
Rated operation power at AC-3, 400 V45kW
Type of control elementRocker lever
Rated operation power at AC-3, 230 V22kW
With integrated auxiliary switchNo
Type of electrical connection of main circuitScrew connection
Device constructionBuilt-in device fixed built-in technique
Rated short-circuit breaking capacity lcu at 400 V, AC150kA
Number of poles3
With integrated under voltage releaseNo
Height195mm
Degree of protection (IP)IP20
Depth149mm
Width105mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMN2-MX90-NA | Circuit-breaker, 3p, Ic=35kA(480V), In=90A, motor.prot, PXR20(LSI), fixed,
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor protection circuit-breaker
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Overload release current setting
36 .. 90A
With thermal protection
Adjustment range undelayed short-circuit release
180 .. 1260A
Phase failure sensitive
Rated permanent current Iu
90A
Switch off technique
Electronic
Rated operating voltage
690 .. 690V
Rated operation power at AC-3, 400 V
45kW
Type of control element
Rocker lever
Rated operation power at AC-3, 230 V
22kW
With integrated auxiliary switch
Type of electrical connection of main circuit
Screw connection
Device construction
Built-in device fixed built-in technique
Rated short-circuit breaking capacity lcu at 400 V, AC
150kA
Number of poles
3
With integrated under voltage release
Height
195mm
Degree of protection (IP)
IP20
Depth
149mm
Width
105mm
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
