NZMN3-PMX250-AVE | Circuit-breaker, 3p, Icu=50kA(415V), In=250A, motor.prot, PXR25(LSI),
Code: 2036660
ManufacturerEaton
Catalog number192334
TypeMotor protection circuit-breaker
CategoryMotor protection circuit-breaker
EAN code4015081928859
Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
Adjustment range undelayed short-circuit release2 - 18A
With thermal protectionYes
Rated operating voltage690 - 690V
Switch off techniqueElectronic
Phase failure sensitiveYes
Rated operation power at AC-3, 230 V75kW
Type of electrical connection of main circuitOther
Device constructionBuilt-in device slide-in technique (withdrawable)
With integrated under voltage releaseNo
Type of control elementRocker lever
With integrated auxiliary switchNo
Width185mm
Degree of protection (IP)IP20
Height260mm
Depth346mm
Rated operation power at AC-3, 400 V132kW
Rated permanent current Iu250A
Number of poles3
Overload release current setting100 - 250A
Rated short-circuit breaking capacity lcu at 400 V, AC35kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMN3-PMX250-AVE | Circuit-breaker, 3p, Icu=50kA(415V), In=250A, motor.prot, PXR25(LSI),
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor protection circuit-breaker
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Adjustment range undelayed short-circuit release
2 .. 18A
With thermal protection
Rated operating voltage
690 .. 690V
Switch off technique
Electronic
Phase failure sensitive
Rated operation power at AC-3, 230 V
75kW
Type of electrical connection of main circuit
Other
Device construction
Built-in device slide-in technique (withdrawable)
With integrated under voltage release
Type of control element
Rocker lever
With integrated auxiliary switch
Width
185mm
Degree of protection (IP)
IP20
Height
260mm
Depth
346mm
Rated operation power at AC-3, 400 V
132kW
Rated permanent current Iu
250A
Number of poles
3
Overload release current setting
100 .. 250A
Rated short-circuit breaking capacity lcu at 400 V, AC
35kA
