Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •EATON
Technical specifications
Rated permanent current Iu1000A
Overload release current setting400 - 1000A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz37kA
Rated voltage690 - 690V
Adjustment range undelayed short-circuit release2 - 18A
Adjustment range short-term delayed short-circuit release2 - 10A
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionNo
Type of electrical connection of main circuitScrew connection
DIN rail (top hat rail) mounting optionalNo
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Suitable for DIN rail (top hat rail) mountingNo
With switched-off indicatorNo
With integrated under voltage releaseNo
Position of connection for main current circuitFront side
Number of poles4
Type of control elementRocker lever
Motor drive optionalYes
Complete device with protection unitYes
Degree of protection (IP)IP20
Motor drive integratedNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMN4-4-VX1000/VAR | Circuit-breaker, 4p, Icu=50kA(415V), In=1000A, selective, PXR20 (lsi), fixed,
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Rated permanent current Iu
1000A
Overload release current setting
400 .. 1000A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
37kA
Rated voltage
690 .. 690V
Adjustment range undelayed short-circuit release
2 .. 18A
Adjustment range short-term delayed short-circuit release
2 .. 10A
Device construction
Built-in device fixed built-in technique
Integrated earth fault protection
Type of electrical connection of main circuit
Screw connection
DIN rail (top hat rail) mounting optional
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Suitable for DIN rail (top hat rail) mounting
With switched-off indicator
With integrated under voltage release
Position of connection for main current circuit
Front side
Number of poles
4
Type of control element
Rocker lever
Motor drive optional
Complete device with protection unit
Degree of protection (IP)
IP20
Motor drive integrated
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
