NZMN4-4-VX1250-T | Circuit-breaker, 4p, Icu=50kA(415V), In=1250A, selective, PXR20 (lsig), fixed,
Code: 2036723
ManufacturerEaton
Catalog number193322
TypePower circuit-breaker for trafo/generator/installation protection
EAN code9010238016675
Details
- •screw.terminal
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Overload release current setting500 - 1250A
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionYes
Adjustment range undelayed short-circuit release2500 - 37500A
Type of electrical connection of main circuitScrew connection
Suitable for DIN rail (top hat rail) mountingNo
DIN rail (top hat rail) mounting optionalNo
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Type of control elementRocker lever
With integrated under voltage releaseNo
With switched-off indicatorNo
Complete device with protection unitYes
Adjustment range short-term delayed short-circuit release2 - 10A
Position of connection for main current circuitFront side
Motor drive optionalYes
Degree of protection (IP)IP20
Motor drive integratedNo
Rated permanent current Iu1250A
Number of poles4
Rated voltage690 - 690V
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz50kA
