Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •EATON
Technical specifications
Rated permanent current Iu630A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz37kA
Rated voltage690 - 690V
Overload release current setting252 - 630A
Adjustment range short-term delayed short-circuit release2 - 10A
Type of electrical connection of main circuitScrew connection
Device constructionBuilt-in device slide-in technique (withdrawable)
Adjustment range undelayed short-circuit release1260 - 22680A
Suitable for DIN rail (top hat rail) mountingNo
Integrated earth fault protectionNo
Number of auxiliary contacts as normally closed contact0
DIN rail (top hat rail) mounting optionalNo
With switched-off indicatorNo
Number of auxiliary contacts as change-over contact0
With integrated under voltage releaseNo
Number of auxiliary contacts as normally open contact0
Number of poles3
Type of control elementRocker lever
Position of connection for main current circuitConnection at separate chassis part
Motor drive optionalYes
Degree of protection (IP)IP20
Complete device with protection unitYes
Motor drive integratedNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMN4-PX630-AVE | Circuit-breaker, 3p, Icu=50kA(415V), In=630A, selective, PXR25 (lsi), withdrawable
