Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •EATON
Technical specifications
Rated voltage690 - 690V
Rated permanent current Iu100A
Overload release current setting40 - 100A
Type of electrical connection of main circuitOther
DIN rail (top hat rail) mounting optionalNo
With integrated under voltage releaseNo
Type of control elementRocker lever
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz70kA
Degree of protection (IP)IP20
Motor drive integratedNo
Integrated earth fault protectionYes
Number of auxiliary contacts as normally closed contact0
With switched-off indicatorNo
Number of poles4
Number of auxiliary contacts as change-over contact0
Adjustment range short-term delayed short-circuit release2 - 10A
Device constructionBuilt-in device plug-in technique
Complete device with protection unitYes
Adjustment range undelayed short-circuit release2 - 18A
Position of connection for main current circuitConnection at separate chassis part
Number of auxiliary contacts as normally open contact0
Motor drive optionalYes
Suitable for DIN rail (top hat rail) mountingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMS2-4-PX100/VAR-TZ-SVE | Circuit-breaker, 4p, Icu=70kA(415V), In=100A, selective, PXR25
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Rated voltage
690 .. 690V
Rated permanent current Iu
100A
Overload release current setting
40 .. 100A
Type of electrical connection of main circuit
Other
DIN rail (top hat rail) mounting optional
With integrated under voltage release
Type of control element
Rocker lever
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
70kA
Degree of protection (IP)
IP20
Motor drive integrated
Integrated earth fault protection
Number of auxiliary contacts as normally closed contact
0
With switched-off indicator
Number of poles
4
Number of auxiliary contacts as change-over contact
0
Adjustment range short-term delayed short-circuit release
2 .. 10A
Device construction
Built-in device plug-in technique
Complete device with protection unit
Adjustment range undelayed short-circuit release
2 .. 18A
Position of connection for main current circuit
Connection at separate chassis part
Number of auxiliary contacts as normally open contact
0
Motor drive optional
Suitable for DIN rail (top hat rail) mounting
