Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •EATON
Technical specifications
Device constructionBuilt-in device plug-in technique
Integrated earth fault protectionNo
Overload release current setting125 - 160A
Adjustment range undelayed short-circuit release960 - 1600A
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as change-over contact0
With switched-off indicatorNo
DIN rail (top hat rail) mounting optionalNo
Adjustment range short-term delayed short-circuit release0 - 0A
Number of auxiliary contacts as normally closed contact0
Type of electrical connection of main circuitScrew connection
Type of control elementRocker lever
Motor drive integratedNo
Number of auxiliary contacts as normally open contact0
Position of connection for main current circuitBack side
With integrated under voltage releaseNo
Complete device with protection unitYes
Motor drive optionalYes
Degree of protection (IP)IP20
Rated permanent current Iu160A
Number of poles3
Rated voltage690 - 690V
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz70kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMS2-A160-SVE | Circuit-breaker, 3p, Icu=70kA(415V), In=160A, circuit.prot, thermomag, plug-in
