SPPVRT12-15-2+PE-AX | Surge arrester, class T1+T2 (i+ii, B+c), for PV applications 1500V DC,
Code: 2038017
ManufacturerEaton
Catalog numberEP-501961
TypeLightning current arrester for power supply systems
EAN code9010653063018
Details
- •Earthing, lightning and surge protection
- •Lightning current arrester for power supply systems
- •1 KOM
- •EATON
Technical specifications
System configuration DCYes
System configuration ITNo
System configuration TNNo
Specific energy (W/R)6.25kJ/Ohm
Max. continuous voltage DC1500V
Voltage protection level (DC+/DC- - PE)5kV
Voltage protection level (DC+ - DC-)5kV
Voltage protection level L-N5kV
Nominal voltage DC1500V
Construction size3 modular spacing
System configuration TN-SNo
System configuration TN-C-SNo
System configuration TTNo
System configuration TN-CNo
System configuration otherNo
Nominal discharge surge current (8/20)20kA
Max. conductor cross section flexible (fine-strand)25mm²
With remote signalling contactYes
Max. conductor cross section solid (solid, stranded)35mm²
ExhaustingNo
Signalling at the deviceOptic
Degree of protection (IP)IP20
Category type 1Yes
Suitable for outdoor useNo
Integrated backup fuseNo
Mounting methodDIN rail (top hat rail) 35 mm
Lightning impulse current (10/350 µs)5kA
Number of conductors (without earthing)2
Voltage protection level5kV
