1350423 | PTVME 6/S-P RD
Code: 2047715
ManufacturerPhoenix Contact
Catalog number1350423
Type(Knife) disconnect terminal block
EAN code4063151669492
Details
- •Terminal blocks
- •(Knife) disconnect terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Internally connected stagesYes
Number of clamp positions per level2
Inflammability class of insulation material according to with UL94V0
Closing plate requiredYes
Depth54.5mm
Height82mm
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 0.5mm²
ColourRed
Type of electrical connection 2Other
Material insulation bodyOther
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 6mm²
Width8.2mm
Type of electrical connection 1Other
Mounting methodDIN rail (top hat rail) 35 mm
Rated voltage1000V
Connectable conductor cross section solid-core0.5 - 6mm²
Rated current In30A
