Details
- •Programmable logic controllers PLC
- •Fieldbus, decentr. periphery - analogue I/O module
- •1 KOM
- •PHOENIX
Technical specifications
Input, resistance thermometerNo
Input, resistorNo
Input, voltageNo
Voltage type of supply voltageDC
Input, currentNo
Input, thermocoupleNo
Input signal, configurableNo
Output signal configurableNo
Output, currentNo
Output, voltageYes
Resolution of the analogue outputs12Bit
Number of analogue outputs4
Number of analogue inputs0
Analogue inputs configurableNo
Analogue outputs configurableNo
Number of HW-interfaces RS-2320
Number of HW-interfaces industrial Ethernet0
Number of interfaces PROFINET0
Number of HW-interfaces RS-4220
Number of HW-interfaces serial TTY0
Number of HW-interfaces Wireless0
Number of HW-interfaces RS-4850
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Supporting protocol for TCP/IPNo
Supporting protocol for EtherCATNo
Supporting protocol for CANNo
Number of HW-interfaces other0
Supporting protocol for PROFIBUSNo
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusNo
Supporting protocol for DeviceNetNo
Supporting protocol for KNXNo
Supporting protocol for LONNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for ASINo
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for PROFIsafeNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for other bus systemsYes
Supporting protocol for INTERBUS-SafetyNo
Radio standard BluetoothNo
Supporting protocol for SERCOSNo
Radio standard Wi-Fi 802.11No
Radio standard GSMNo
System accessoryYes
IO link masterNo
Radio standard GPRSNo
Radio standard UMTSNo
Rail mounting possibleNo
Fieldbus connection over separate bus coupler possibleYes
Degree of protection (IP)IP20
Type of electric connectionOther
Wall mounting/direct mountingNo
Front built-in possibleNo
Rack-assembly possibleNo
Appendant operation agent (Ex ia)No
Performance level according to EN ISO 13849-1None
Suitable for safety functionsNo
Appendant operation agent (Ex ib)No
Explosion safety category for gasNone
Explosion safety category for dustNone
Width14.9mm
Depth62mm
Height62.2mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1487835 | AXL SE AO4 U -10-10
