3000605 | TB 4-MTD I
Code: 2055213
ManufacturerPhoenix Contact
Catalog number3000605
Type(Knife) disconnect terminal block
EAN code4046356708999
Details
- •Terminal blocks
- •(Knife) disconnect terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Type of electrical connection 2Screw connection
Type of electrical connection 1Screw connection
Connectable conductor cross section multi-wired0.5 - 1.5mm²
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 4mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 0.5mm²
Number of clamp positions per level2
Material insulation bodyOther
Inflammability class of insulation material according to with UL94V0
Width8.2mm
Height58mm
Depth48mm
Internally connected stagesYes
With integrated test socketNo
Type of cross disconnectionNone
Mounting methodDIN rail (top hat rail) 35 mm
Rated voltage800V
Connectable conductor cross section solid-core0.5 - 6mm²
Rated current In32A
Related products
