Details
- •Terminal blocks
- •Fuse terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Rated voltage60V
Connectable conductor cross section multi-wired0.5 - 1.5mm²
Type of electrical connection 2Screw connection
Number of levels1
Type of fuse holderOther
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 2.5mm²
Connectable conductor cross section solid-core0.5 - 6mm²
Mounting methodDIN rail (top hat rail) 35 mm
Type of electrical connection 1Screw connection
Rated current In6.3A
Material insulation bodyOther
Depth48.8mm
Inflammability class of insulation material according to with UL94V0
Width8.15mm
Closing plate requiredYes
Type of fuse insertOther
Height58mm
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 4mm²
