Details
- •Terminal blocks
- •Fuse terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Type of fuse insertOther
Type of fuse holderOther
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 4mm²
Connectable conductor cross section solid-core0.5 - 6mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 4mm²
Connectable conductor cross section multi-wired0.5 - 1.5mm²
Type of electrical connection 1Screw connection
Rated voltage400V
Type of electrical connection 2Screw connection
Number of levels2
Inflammability class of insulation material according to with UL94V0
Height86.55mm
Depth77.985mm
Material insulation bodyOther
Width8.15mm
Mounting methodDIN rail (top hat rail) 35 mm
Closing plate requiredNo
Rated current In30A
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
3246819 | TB 4-2L-HESILA 250 (5X20) I
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Terminal blocks
- Fuse terminal block
- 50 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of fuse insert
Other
Type of fuse holder
Other
Connectable conductor cross section fine-strand without cable end sleeve
0.5 .. 4mm²
Connectable conductor cross section solid-core
0.5 .. 6mm²
Connectable conductor cross section fine-strand with cable end sleeve
0.5 .. 4mm²
Connectable conductor cross section multi-wired
0.5 .. 1.5mm²
Type of electrical connection 1
Screw connection
Rated voltage
400V
Type of electrical connection 2
Screw connection
Number of levels
2
Inflammability class of insulation material according to with UL94
V0
Height
86.55mm
Depth
77.985mm
Material insulation body
Other
Width
8.15mm
Mounting method
DIN rail (top hat rail) 35 mm
Closing plate required
Rated current In
30A
