Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •SCHNEIDER
Technical specifications
Number of protected poles1
Rated voltage230V
Current limiting class3
Rated short-circuit breaking capacity according to IEC 60947-2-kA
Rated short-circuit breaking capacity according to EN 608986kA
Voltage typeAC
Built-in depth44mm
Rated current10A
Release characteristicC
Rated insulation voltage Ui400V
Rated fault current0.03A
Leakage current typeAC
Surge current capacity0.25kA
Over voltage category3
Pollution degree3
Width in number of modular spacings2
Power loss2.9W
Frequency50/60 Hz
Degree of protection (IP)IP20
Concurrently switching neutral conductorYes
Suitable for flush-mounted installationNo
Connectable conductor cross section solid-core1 - 16mm²
Connectable conductor cross section multi-wired1 - 10mm²
With interlocking deviceYes
Ambient temperature during operating-5 - 60°C
Flush-mounted installationNo
Number of poles (total)2
Anti-nuisance tripping versionNo
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Disconnection characteristicUndelayed
Rated short-circuit breaking capacity according to EN 610096kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
A9DE3610 | SKLOPKA KZS iDPNNVigi 6kA 1P+N 10A C 30mA
