Details
- •Connection devices
- •Box/housing for built-in mounting in the wall/ceiling
- •1 KOM
- •OBO
Technical specifications
Provided with revolving ringNo
ConnectableNo
Length-mm
Width-mm
Internal depth-mm
Suitable for wall/board thicknessmm
For number of electric fittings-
Number of non-adjustable device fixing lugs-
Number of adjustable device fixing lugs-
Suitable for cable diameter- - -mm
Pipe lockingNo
Pipe locking optionalNo
Number of included spouts-
Transparent coverNo
SealableNo
Max. conductor cross section-mm²
With screeningNo
Air tightNo
Number of poles of the clamp-
Luminaire hook mountingNo
Clamp position fixedNo
With partition panelNo
Compliant with BS 4662No
Mounting switching equipmentScrewing
Construction typeBuilt-in installation box (device box)
Housing feed-through by seal membraneYes
Depth46 - 46mm
Housing feed-through by break-out openingNo
Number of inlets8
ColourBlack
Housing feed-through by step membraneNo
Halogen freeYes
For tube diameter20/25 mm
ModelSingle
Cover attachmentScrewed
Housing feed-through by nozzleNo
With screwsNo
Inlet from the rearYes
ShapeRound
MaterialPlastic
Diameter60mm
Degree of protection (IP)IP30
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2003706 | UG 46-L
