Details
- •Connection devices
- •Box/housing for built-in mounting in the wall/ceiling
- •1 KOM
- •OBO
Technical specifications
Construction typeDevice connection box (round/square)
ModelSingle
ConnectableNo
Provided with revolving ringNo
ShapeRound
Diameter60mm
Length-mm
Depth66 - 66mm
Suitable for wall/board thicknessmm
Width-mm
Internal depth-mm
With screwsNo
Mounting switching equipmentScrew or spread out
For number of electric fittings-
Number of non-adjustable device fixing lugs-
Housing feed-through by break-out openingNo
Housing feed-through by seal membraneYes
Pipe lockingNo
For tube diameter20/25 mm
Number of adjustable device fixing lugs-
Inlet from the rearYes
Pipe locking optionalNo
Number of included spouts-
Suitable for cable diameter- - -mm
MaterialPlastic
Housing feed-through by step membraneNo
Number of inlets14
Halogen freeYes
Degree of protection (IP)IP30
ColourBlack
Transparent coverNo
Housing feed-through by nozzleNo
SealableNo
Cover attachmentScrewed
With screeningNo
Air tightNo
Max. conductor cross section-mm²
Clamp position fixedNo
Luminaire hook mountingNo
Number of poles of the clamp-
Compliant with BS 4662No
With partition panelNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2003708 | UG 66-L
