Details
- •Connection devices
- •Box/housing for built-in mounting in the wall/ceiling
- •1 KOM
- •OBO
Technical specifications
Suitable for wall/board thicknessmm
ModelSingle
Provided with revolving ringNo
Construction typeDevice connection box (round/square)
For number of electric fittings-
Depth66 - 66mm
Mounting switching equipmentScrew or spread out
With screwsYes
Internal depth-mm
ConnectableNo
Number of non-adjustable device fixing lugs-
Number of adjustable device fixing lugs-
Housing feed-through by nozzleNo
Housing feed-through by break-out openingNo
Suitable for cable diameter- - -mm
Housing feed-through by seal membraneYes
Housing feed-through by step membraneNo
For tube diameter20/25 mm
Pipe locking optionalNo
Inlet from the rearYes
Pipe lockingNo
Number of inlets14
MaterialPlastic
ColourBlack
Number of included spouts-
Transparent coverNo
Halogen freeYes
With screeningNo
Air tightNo
SealableNo
Number of poles of the clamp-
Max. conductor cross section-mm²
Clamp position fixedNo
Cover attachmentScrewed
Compliant with BS 4662No
With partition panelNo
Luminaire hook mountingNo
Width-mm
ShapeRound
Diameter60mm
Length-mm
Degree of protection (IP)IP30
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2003709 | UG 66-GS-L
