Details

  • •Connection devices
  • •Box/housing for surface mounting on the wall/ceiling
  • •1 KOM
  • •OBO

Technical specifications

Mounting in the soilNo
Mounting under waterNo
Diameter-mm
Transparent coverNo
With casting compoundNo
SealableNo
CastableNo
Explosion-tested versionNo
Length240mm
Number of inlets16
Inlet from the rearYes
Type of housing feed-throughTrimmable step membrane
Halogen freeYes
TackableYes
With screeningNo
Operating temperature-5 - 60°C
For Ex-zone gasNone
Cover attachmentScrewed
WeatherproofNo
Rated insulation voltage Ui500V
For Ex-Zone dustNone
Circuit integrityNone
Mounting methodWall-/ceiling mounting
ColourGrey
Width190mm
Depth95mm
ShapeRectangular
Equipped withNone
MaterialPlastic
Max. conductor cross section-mm²
Degree of protection (IP)IP66
