Details
- •Industrial socket/plug applications
- •Panel-mounted CEE socket outlet (IEC 60309)
- •1 KOM
- •OBO
Technical specifications
IEC-amperage16A
Voltage according to EN 60309-2400 V (50+60 Hz) red
Degree of protection (IP)IP44
Connection systemScrew less terminal
Rated voltage400 - 400V
Number of poles5
RAL-number-
Rated frequencyHz
Amperage according to UL/CSA (for UL-version)-A
Clock hour position-h
Angle of plugStraight
Military modelNo
Drill hole distance vertical60mm
Flange size vertical75mm
Drill hole distance horizontal60mm
Flange size horizontal75mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
6109874 | CEE-16A
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Industrial socket/plug applications
- Panel-mounted CEE socket outlet (IEC 60309)
- 1 KOM
- OBO
DetailsTechnical specifications
Technical specifications
IEC-amperage
16A
Voltage according to EN 60309-2
400 V (50+60 Hz) red
Degree of protection (IP)
IP44
Connection system
Screw less terminal
Rated voltage
400 .. 400V
Number of poles
5
RAL-number
-
Rated frequency
Hz
Amperage according to UL/CSA (for UL-version)
-A
Clock hour position
-h
Angle of plug
Straight
Military model
Drill hole distance vertical
60mm
Flange size vertical
75mm
Drill hole distance horizontal
60mm
Flange size horizontal
75mm
