Details
- •Industrial socket/plug applications
- •Charging device E-Mobility
- •1 KOM
- •OBO
Technical specifications
Max. output current DC-A
Nominal connection power22kW
Depth136mm
Width340mm
Output voltage at DCV
Input voltageV
Installation side connection model3-phase
Number of charging units1
Number of vehicle connectors Type 10
Height370mm
Number of vehicle connectors Type 1 CCS0
Max. power per charging point22kW
Mounting methodWall mounting
Number of vehicle connectors Type 2 CCS0
Number of vehicle connectors Type 21
Number of socket outlets GB0
Number of vehicle connectors GB AC0
Number of socket outlets Type 20
Number of vehicle connectors GB DC0
Number of CEE socket outlets0
Number of vehicle connectors CHAdeMO0
Number of socket outlets Type 30
With house connection boxNo
Number of earth leakage circuit breakers type A0
Length of charging cable-m
Charging cable lockable at charging deviceNo
Number of household socket outlets0
DC residual current detectionNo
Number of earth leakage circuit breakers type B0
With circuit breakerNo
Network-enabled as a masterNo
Network-enabled as an extenderNo
Networkable via LANNo
Contactor welding detectionNo
Networkable via Wi-FiNo
Long-Term Evolution (LTE)No
NFC (Near Field Communication)No
With energy meterNo
With key switchNo
Static load management integratedNo
With built-in RFID card readerNo
With displayNo
Suitable for dynamic load managementNo
Plug and charge (ISO 15118)No
Degree of protection (IP)IP66
Compatible with Apple HomeKitNo
Compatible with Google AssistantNo
Material housingPlastic
IFTTT support availableNo
Radio standard 5GNo
Impact strengthIK08
Compatible with Amazon AlexaNo
Operation and configuration by appNo
Export of charging logsNo
Integrated backendNo
Connectable conductor cross sectionmm²
Calibration law compliantNo
With MID compliant energy meterNo
