Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Rated permanent current Iu3600A
Rated voltage635 - 635V
Overload release current setting1440.0 - 3600A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz-kA
Adjustment range short-term delayed short-circuit release2160.0 - 36000A
Power loss578W
Integrated earth fault protectionYes
Adjustment range undelayed short-circuit release5400.0 - 54000A
DIN rail (top hat rail) mounting optionalNo
Device constructionBuilt-in device fixed built-in technique
With switched-off indicatorYes
Number of auxiliary contacts as normally open contact0
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact4
With integrated under voltage releaseNo
Type of electrical connection of main circuitBolt connection
Number of poles3
Position of connection for main current circuitBack side
Complete device with protection unitYes
Motor drive optionalYes
Type of control elementPush button
Motor drive integratedNo
Degree of protection (IP)IP30
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA077930R1 | E4.2H-A3600EkipDipLSIG3pFVR
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated permanent current Iu
3600A
Rated voltage
635 .. 635V
Overload release current setting
1440.0 .. 3600A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
-kA
Adjustment range short-term delayed short-circuit release
2160.0 .. 36000A
Power loss
578W
Integrated earth fault protection
Adjustment range undelayed short-circuit release
5400.0 .. 54000A
DIN rail (top hat rail) mounting optional
Device construction
Built-in device fixed built-in technique
With switched-off indicator
Number of auxiliary contacts as normally open contact
0
Suitable for DIN rail (top hat rail) mounting
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as change-over contact
4
With integrated under voltage release
Type of electrical connection of main circuit
Bolt connection
Number of poles
3
Position of connection for main current circuit
Back side
Complete device with protection unit
Motor drive optional
Type of control element
Push button
Motor drive integrated
Degree of protection (IP)
IP30
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
