Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Type of electrical connection of main circuitConnection at separate chassis part
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz-kA
Adjustment range undelayed short-circuit release6000.0 - 60000A
Rated voltage1000 - 1000V
Overload release current setting1600.0 - 4000A
Adjustment range short-term delayed short-circuit release2400.0 - 40000A
Rated permanent current Iu4000A
Number of auxiliary contacts as normally closed contact0
Device constructionBuilt-in device slide-in technique (withdrawable)
Integrated earth fault protectionNo
Number of auxiliary contacts as normally open contact0
With switched-off indicatorYes
Suitable for DIN rail (top hat rail) mountingNo
With integrated under voltage releaseNo
Power loss900W
DIN rail (top hat rail) mounting optionalNo
Number of auxiliary contacts as change-over contact4
Motor drive integratedNo
Number of poles3
Motor drive optionalYes
Degree of protection (IP)IP30
Position of connection for main current circuitConnection at separate chassis part
Complete device with protection unitYes
Type of control elementPush button
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA121099R1 | E4.2S/E104000EkipDipLSI3pWMP
