Details

  • •Low-voltage industrial components
  • •Power circuit-breaker for trafo/generator/installation protection
  • •1 KOM
  • •ABB

Technical specifications

Adjustment range short-term delayed short-circuit release- - -A
Integrated earth fault protectionNo
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz100kA
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as change-over contact4
Number of auxiliary contacts as normally closed contact0
With integrated under voltage releaseNo
DIN rail (top hat rail) mounting optionalNo
Power loss465W
Number of auxiliary contacts as normally open contact0
With switched-off indicatorYes
Type of electrical connection of main circuitBolt connection
Adjustment range undelayed short-circuit release6000 - 60000A
Overload release current setting1600 - 4000A
Device constructionBuilt-in device fixed built-in technique
Rated voltage690 - 690V
Rated permanent current Iu4000A
Number of poles4
Position of connection for main current circuitBack side
Type of control elementPush button
Complete device with protection unitYes
Degree of protection (IP)IP30
Motor drive optionalYes
Motor drive integratedNo
