1SDA128848R1 | E6.3V4000EkipAwareLSIG3pFHR
Code: 2071065
ManufacturerABB
Catalog number1SDA128848R1
TypePower circuit-breaker for trafo/generator/installation protection
EAN code8056221304771
Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Rated permanent current Iu4000A
Rated voltage690 - 690V
Overload release current setting1600.0 - 4000A
Adjustment range short-term delayed short-circuit release2400.0 - 40000A
Integrated earth fault protectionYes
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz150kA
Power loss309W
Adjustment range undelayed short-circuit release6000.0 - 60000A
Type of electrical connection of main circuitBolt connection
Device constructionBuilt-in device fixed built-in technique
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as normally open contact0
DIN rail (top hat rail) mounting optionalNo
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact4
With integrated under voltage releaseNo
With switched-off indicatorYes
Number of poles3
Position of connection for main current circuitBack side
Complete device with protection unitYes
Motor drive integratedNo
Type of control elementPush button
Degree of protection (IP)IP30
Motor drive optionalYes
