Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Adjustment range undelayed short-circuit release1200.0 - 12000A
Device constructionBuilt-in device fixed built-in technique
Power loss50W
Type of electrical connection of main circuitBolt connection
Integrated earth fault protectionYes
DIN rail (top hat rail) mounting optionalNo
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as normally closed contact0
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz50kA
Rated permanent current Iu800A
Rated voltage690 - 690V
Adjustment range short-term delayed short-circuit release480.0 - 8000A
Overload release current setting320.0 - 800A
With switched-off indicatorYes
With integrated under voltage releaseNo
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact4
Position of connection for main current circuitBack side
Motor drive integratedNo
Degree of protection (IP)IP30
Motor drive optionalYes
Complete device with protection unitYes
Number of poles4
Type of control elementPush button
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA128861R1 | E1.3C800EkipAwareLSIG4pFF
