Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Overload release current setting800.0 - 2000A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz85kA
Power loss212W
Rated voltage690 - 690V
Adjustment range undelayed short-circuit release3000.0 - 30000A
Number of auxiliary contacts as normally closed contact0
Suitable for DIN rail (top hat rail) mountingNo
DIN rail (top hat rail) mounting optionalNo
Device constructionBuilt-in device fixed built-in technique
Rated permanent current Iu2000A
Number of auxiliary contacts as change-over contact4
Integrated earth fault protectionYes
With switched-off indicatorYes
Number of auxiliary contacts as normally open contact0
Adjustment range short-term delayed short-circuit release1200.0 - 20000A
Type of electrical connection of main circuitBolt connection
With integrated under voltage releaseNo
Type of control elementPush button
Motor drive optionalYes
Degree of protection (IP)IP30
Complete device with protection unitYes
Position of connection for main current circuitBack side
Motor drive integratedNo
Number of poles4
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA128887R1 | E2.3S2000EkipAwareLSIG4pFHR
