Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz42kA
Overload release current setting320.0 - 800A
Type of electrical connection of main circuitConnection at separate chassis part
Adjustment range undelayed short-circuit release1200.0 - 12000A
DIN rail (top hat rail) mounting optionalNo
Rated permanent current Iu800A
Power loss100W
Integrated earth fault protectionYes
Device constructionBuilt-in device slide-in technique (withdrawable)
Rated voltage690 - 690V
Adjustment range short-term delayed short-circuit release480.0 - 8000A
With switched-off indicatorYes
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Suitable for DIN rail (top hat rail) mountingNo
With integrated under voltage releaseNo
Number of auxiliary contacts as change-over contact4
Position of connection for main current circuitConnection at separate chassis part
Number of poles3
Motor drive optionalYes
Type of control elementPush button
Complete device with protection unitYes
Motor drive integratedNo
Degree of protection (IP)IP30
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA128924R1 | E1.3B800EkipAwareLSIG3pWMP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
42kA
Overload release current setting
320.0 .. 800A
Type of electrical connection of main circuit
Connection at separate chassis part
Adjustment range undelayed short-circuit release
1200.0 .. 12000A
DIN rail (top hat rail) mounting optional
Rated permanent current Iu
800A
Power loss
100W
Integrated earth fault protection
Device construction
Built-in device slide-in technique (withdrawable)
Rated voltage
690 .. 690V
Adjustment range short-term delayed short-circuit release
480.0 .. 8000A
With switched-off indicator
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Suitable for DIN rail (top hat rail) mounting
With integrated under voltage release
Number of auxiliary contacts as change-over contact
4
Position of connection for main current circuit
Connection at separate chassis part
Number of poles
3
Motor drive optional
Type of control element
Push button
Complete device with protection unit
Motor drive integrated
Degree of protection (IP)
IP30
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
