Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Adjustment range short-term delayed short-circuit release1920.0 - 32000A
Integrated earth fault protectionYes
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz66kA
DIN rail (top hat rail) mounting optionalNo
Device constructionBuilt-in device slide-in technique (withdrawable)
Adjustment range undelayed short-circuit release4800.0 - 48000A
Power loss743W
Type of electrical connection of main circuitConnection at separate chassis part
Rated voltage690 - 690V
Number of auxiliary contacts as change-over contact4
With switched-off indicatorYes
Suitable for DIN rail (top hat rail) mountingNo
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
With integrated under voltage releaseNo
Overload release current setting1280.0 - 3200A
Rated permanent current Iu3200A
Number of poles4
Position of connection for main current circuitConnection at separate chassis part
Complete device with protection unitYes
Motor drive integratedNo
Type of control elementPush button
Motor drive optionalYes
Degree of protection (IP)IP30
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA129013R1 | E4.3N3200EkipAwareLSIG4pWMP
